1. I typed http://192.168.10.1 in my Internet Browser's Address Bar, but an error message
says “The page cannot be displayed.” How can I get into the TEW-651BR's web
configuration page?
1. Check your hardware settings again by following the instructions in Section 2.
2. Make sure the LAN and WLAN lights are lit.
3. Make sure your Network adapter’s TCP/IP settings are set to Obtain an IP address
automatically (see the steps below).
4. Press on the factory reset button for 15 seconds.
Troubleshooting
Windows 7
Windows Vista
1. Go into the Control Panel, click Network and
Sharing Center, click Change Adapter
Settings and then right-click the Local Area
Connection icon and then click Properties.
2. Click Internet Protocol Version 4(TCP/IPv4) and
then click Properties. Then click on Obtain an IP
address automatically.
1. Go into the Control Panel, click Network
and Internet, click Network and Sharing
Center, click Manage Network Connections
and then right-click the Local Area
Connection icon and then click Properties.
2. Click Internet Protocol Version 4(TCP/IPv4) and
then click Properties. Then click on Obtain an IP
address automatically.
Windows XP/2000
1. Go into the Control Panel, double-click the
Network Connections icon and then right-
click the Local Area Connection icon and
then click Properties.
9

Other manuals for TRENDnet TEW-651BR

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TRENDnet TEW-651BR and is the answer not in the manual?

TRENDnet TEW-651BR Specifications

General IconGeneral
I/O ports1 x 10/100Mbps Auto-MDIX WAN 4 x 10/100Mbps Auto-MDIX LAN
Indoor range100m
Outdoor range300m
Frequency range2.412 - 2.484 GHz
xDSL connectionNo
Dimensions (WxDxH)150 x 110 x 30 mm
Power requirements5V DC, 1.2A
Output power description802.11b: 15dBm @ 11Mbps; 802.11g: 15dBm @ 54Mbps; 802.11n: 13dBm @ 150Mbps
Minimum system requirementsInternet Explorer 6.0 +, Firefox, Safari
Compatible operating systemsWindows, Linux, & Mac
Supported data transfer rates802.11b: 11Mbps; 802.11g: 54Mbps; 802.11n: 150Mbps;
WLAN data transfer rates supported150 Mbit/s
Ethernet LANYes
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Receiver sensitivity802.11b: -85dBm @ 11Mbps 802.11g: -68dBm @ 54Mbps 802.11n: -62dBm @ 150Mbps
Supported network protocolsDynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP
ModulationQPSK
Channels quantity13 channels
Antennas quantity1
Antenna gain level (max)2 dBi
Ethernet LAN (RJ-45) ports4
LED indicatorsStatus, LAN1 - LAN4, WAN, WLAN
CertificationCE, FCC
Power consumption (typical)3.5 W
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 95 %
Weight and Dimensions IconWeight and Dimensions
Weight225 g
