TRENDnet TEW-711BR User Manual

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-711BR
1
Product Overview
TEW-711BR
Package Contents
In addition to your router, the package includes:
• Multi-Language Quick Installation Guide
• CD-ROM (User’s Guide)
• Network cable (1.5 m / 5 ft.)
• Power adapter (5V DC, 1A)
If any package contents are missing or damaged, please contact the retail store, online
retailer, or reseller/distributor from which the product was purchased.
Features
TRENDnet’s N150 Wireless Home Router, model TEW-711BR, provides reliable 150Mbps
wireless n speed and coverage to share files, play games, and surf the Internet.
Advanced encryption protects your wireless network, Access Control tools help block
unwanted Websites and unknown users, and embedded GREENnet technology reduces
power consumption by up to 50%.
WMM® Quality of Service (QoS) technology prioritizes gaming, Internet calls, and video
streams.
Wi-Fi Protected Setup (WPS) connects other WPS supported wireless adapters at the
touch of a button. LEDs on the front of the router convey device status. Network wired
devices to the four Fast Ethernet ports on the back of the router.
 4 x 10/100Mbps Auto-MDIX LAN ports
 1 x 10/100Mbps Auto-MDIX WAN port (Internet)
 High-speed data rates of up to 150Mbps based on IEEE 802.11n*
 Compliant with IEEE 802.11b/g standards
 GREENnet technology reduces power consumption by up to 50%
 Compatible with most popular cable/DSL Internet service providers using
Dynamic/Static IP, PPPoE, PPTP and L2TP protocols
 Support for IPv6 (Internet Protocol v6) 6rd (IPv6 rapid deployment) DHCPv4,
manual and automatic configuration
 One touch wireless connection to wireless clients using the WPS button
 Advanced wireless security of up to WPA2-RADIUS
 Internet Access Control (MAC Address, Domain, and IP Filtering)
 Easy setup via Web browser using Internet Explorer 6.0 or above, Firefox 2.0
or above, Chrome, Opera, Safari
 Firewall features Network Address Translation (NAT)
 Virtual server and Application Level Gateway (ALG) services for special
Internet applications
 Universal Plug and Play (UPnP) for auto discovery and support for device
configuration of Internet applications
 Dynamic DNS Client for dynamic Internet IP resolution
 Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization
 Indoor range up to 100 meters (330 ft.)* depending on the environment
 Outdoor range up to 300 meters (980 ft.)* depending on the environment
 3-year limited warranty

TRENDnet TEW-711BR Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Receiver sensitivity	802.11b: -85dBm @ 11Mbps 802.11g: -68dBm @ 54Mbps 802.11n: -62dBm @ 150Mbps
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Maximum indoor range	100 m
Maximum outdoor range	300 m
WLAN data transfer rate (max)	150 Mbit/s
Input current	1 A
Rack mounting	No
Frequency band	2.4 GHz
Operating temperature (T-T)	32 - 104 °F
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	5
Supported network protocols	PPPoE, PPTP, L2TP, UPnP
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPA2-PSK
Antennas quantity	1
Antenna gain level (max)	2 dBi
Certification	CE, FCC, RoHS, CSMA/CA, ACK, ETSI
Power consumption (typical)	2.8 W
Storage temperature (T-T)	-10 - 70 °C
Product color	Black
LED indicators	LAN, Status, WAN, WLAN

Weight and Dimensions

Depth	109 mm
Width	158 mm
Height	34 mm
Weight	204 g
