TRENDnet TEW-755AP2KAC User Manual

© Copyright 2017 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-755AP2KAC / TEW-821DAP2KAC
40
 Client
 WDS AP
 WDS Bridge
 WDS Station
 Repeater
Management/Monitoring
 Web based management
 SNMP v1/v3
 STP
 Event logging
 Ping test
 Traceroute
 CLI
Access Control
 Wireless encryption: WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS
 MAC filter
 Maximum client limit
QoS
 WMM
 Traffic shaping per SSID
SSID
 Up to 8 SSIDs per wireless band (16 total) per access point
Frequency
 2.4 GHz: 2.412 - 2.472 GHz
 5 GHz: 5.180 – 5.8525 GHz
Wireless Channels
 2.4 GHz: FCC: 1-11, ETSI: 1 – 13
 5 GHz: FCC: 36, 40, 44, 48, 149, 153, 157, 161 and 165 ETSI: 36, 40, 44, 48 (52,
56, 60, 64, 100,104,108,112,116, 132,136,140)***
Modulation
 DBPSK/DQPSK/CCK for DSSS technique
 BPSK/QPSK/16-QAM/64-QAM/256-QAM for OFDM technique
Antenna Gain
 2.4 GHz: 2 x 4 dBi
 5 GHz: 2 x 4 dBi
Wireless Output Power/Receiving Sensitivity
 802.11a: FCC: 24 dBm, CE: 22 dBm (Max.) /-65 dBm (typical) @ 54 Mbps
 802.11b: FCC: 23 dBm (Max.), CE: 10 dBm (Max) /-83 dBm (typical) @ 11 Mbps
 802.11g: 19 dBm (Max.), CE: 12 dBm (Max.) /-65 dBm (typical) @ 54 Mbps
 802.11n: FCC: 19 dBm (Max.), CE: 12 dBm (Max.) /-64 dBm (typical) @ 300
Mbps 2.4 GHz
 802.11n: FCC: 24 dBm, CE: 22 dBm (Max.)/-61 dBm (typical) @ 300 Mbps 5 GHz
 802.11ac: FCC: 15 dBm, CE: 22 dBm (Max.)/-51 dBm (typical) @ 867 Mbps
Power
 12 V DC/ 1 A or PoE, consumption: 9.6 Watts Max.
Operating Temperature
 0 – 40 °C (32 – 104 °F)
Operating Humidity
 Max. 95 % non-condensing
Dimensions
 187 x 187 x 46 mm (7.3 x 7.3 x 1.8 in.) per access point
Weight
 408 g (14.4 oz.) per access point
Certifications
 CE
 FCC
 IC
