- 29 - Rev. 1.00.2.1.63
CONNECT 38000 EC* 73
CONNECT 38400 EC* 28
CONNECT 38666 EC* 106
CONNECT 40000 EC* 74
CONNECT 41333 EC* 107
CONNECT 42000 EC* 75
CONNECT 42666 EC* 108
CONNECT 44000 EC* 76
CONNECT 45333 EC* 109
CONNECT 46000 EC* 77
CONNECT 46666 EC* 110
CONNECT 48000 EC* 78
CONNECT 49333 EC* 111
CONNECT 50000 EC* 79
CONNECT 50666 EC* 112
CONNECT 52000 EC* 80
CONNECT 53333 EC* 113
CONNECT 54000 EC* 81
CONNECT 54666 EC* 114
CONNECT 56000 EC* 82
CONNECT 57600 EC* 18
CONNECT 115200 EC* 87
Note:
* EC only appear when the extended result codes configuration option is enabled. EC is
replaced by one of the following symbols, depending upon the error control method used:
V.42bis - V.42 error control and V.42bis data compression.
V.42 - V.42 error control only.
MNP5 - MNP class 4 error control and MNP class 5 data compression.
MNP4 - MNP class 4 error control only.
NoEC - No error control protocol.
Verbose Code Numeric Code
