Appendix 3 S-Register Summary
S0* No. of rings to start auto-answer 0 0-255 ring
S1* Ring count 0 0-255 ring
S2* Escape character 43 0-255 ASCII
S3 Carriage return character 13 0-127 ASCII
S4 Line feed character 10 0-127 ASCII
S5 Backspace character 8 0-32,127 ASCII
S6* Wait before dialing 2 2-65 second
S7* Wait for carrier 50 1-255 second
S8* Pause time for dial modifier , 2 0-65 second
S10* Lost carrier hang up delay 20 1-254 0.1second
S11* DTMF dialing speed 95 50-150 msec
S12* Escape guard time 50 0-255 20 msec
S14* Bit-mapped register - 0-255 -
Bit 0,1,2 Reserved
Bit 3 = 0 V0 is selected
= 1 V1 is selected
Bit 4,5 Reserved
Bit 6 = 0 10 PPS pulse dialing(&P0, &P1)
= 1 20 PPS pulse dialing(&P2)
Bit 7 Reserved
S21* Bit-mapped register - 0-255 -
Bit0,1,2 Reserved
Bit 4-3 = 00 &D0 is selected
= 01 &D1 is selected
= 10 &D2 is selected
= 11 &D3 is selected
Bit 5 = 0 &C0 is selected
= 1 &C1 is selected
Bit 6,7 Reserved
S22* Bit-mapped register - 0-255 -
Bit 0,1,2,3 Reserved
Bit 6-4 = 000 X0 is selected
= 001 Reserved
= 010 Reserved
= 011 Reserved
= 100 X1 is selected
