TRENDnet TI-G50 User Manual

2
3. Hardware Installation
ŸThe TI-G50 can be placed on a desktop, wall, or mounted to a DIN-rail.
1. Attach the DIN-rail mount bracket to the switch.
2. Position the switch in front of the DIN-rail and hook the mount over the top
of the rail.
Mounting the switch Releasing the switch
DIN-rail Mounting Instructions
3. Rotate the switch down towards the rail to lock it into place. You will know it
is secure when you hear the click.
4. To remove the switch, pull down to clear the bottom of the DIN-rail and
rotate up, away from the rail.

TRENDnet TI-G50 Specifications

General

Stackable	-
Certification	FCC CE
Rack mounting	No
Housing material	Metal
International Protection (IP) code	IP30
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	5
Full duplex	Yes
Networking standards	IEEE 802.3u, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
MAC address table	8000 entries
Operating temperature (T-T)	-40 - 75 °C
Power consumption (max)	2.76 W
Mean time between failures (MTBF)	510304 h
Power requirements	12 - 56 VDC / 18 - 36 VAC
Harmonized System (HS) code	85176990
Switch type	Unmanaged

Weight and Dimensions

Depth	82 mm
Width	113 mm
Height	31 mm
Weight	168 g
