Page #4 background imageLoading...
Page #4 background image
3
1. Attach the wall mount plates to the switch.
Wall Mounting Instructions
2. Mount the switch.
ŸTurn off the power before connecting any module or wire. The correct power
supply voltage (12 - 56 V DC or 18 - 36 V AC) is listed on the product label.
Check the voltage of your power source to make sure that you are using the
correct part. Do NOT use voltage greater than 12 - 56 V DC or 18 - 36 V AC,
as specified on the product label.
ŸCalculate the maximum possible current in each power wire and common
wire. Observe all electrical codes dictating the maximum current allowable
for each wire size. If the current surpasses the maximum ratings, the wiring
could overheat, causing serious damage to your equipment.
Safety Note
!

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TRENDnet TI-G50 and is the answer not in the manual?

TRENDnet TI-G50 Specifications

General IconGeneral
Stackable-
CertificationFCC CE
Rack mountingNo
Housing materialMetal
International Protection (IP) codeIP30
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity5
Full duplexYes
Networking standardsIEEE 802.3u, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab
Copper ethernet cabling technology1000BASE-T, 100BASE-TX, 10BASE-T
MAC address table8000 entries
Operating temperature (T-T)-40 - 75 °C
Power consumption (max)2.76 W
Mean time between failures (MTBF)510304 h
Power requirements12 - 56 VDC / 18 - 36 VAC
Harmonized System (HS) code85176990
Switch typeUnmanaged
Weight and Dimensions IconWeight and Dimensions
Depth82 mm
Width113 mm
Height31 mm
Weight168 g
