OPERATING INSTRUCTIONS
Turning the open burners on and off:
• To light the burner, push in the required knob and turn it anti clockwise to the position shown in Fig 2.
• Whilst pushing in the knob, light the burner, and hold in for a further 15 seconds, to allow the
thermocouple to activate . If the flame goes out repeat this operation.
• The burner flame can be adjusted by setting the knob position at a point between Fig. 2 and Fig. 3.
• To turn off the flame -- turn the knob in a clockwise direction to the "OFF" position. Fig. 1
8
Fig. 1 - Off Fig. 2 - Ignition &
Low Flame
Fig. 3 - High Flame
