InRoom Silver Center
Tilting Instructions
1. Determine the angle required to properly aim the center channel
speaker at the listeners' ears.
2. Place the speaker upside down, and pull the feet out about 1".
3. Using the index marks on the inside face of each foot as a guide,
reinsert the feet at the required angle. Ensure that both feet are
installed so that the same number of index marks is showing on
each foot.
4. Turn the speaker over and place it in the listening position.
Check the alignment to the listeners' ears and readjust the angle
if necessary.
0º
+3º
+6º
+9º
+12º
0º
-3º
-6º
-9º
Angle the speaker up when placing it below the screen.
Angle the speaker down when placing it above the screen.
-12º
-12º
-9º
-6º
-3º
0º
Grasp here
and pull up.
0º
+12º
+9º
+6º
+3º
0º
0º
