TECHNICAL SPECIFICATIONS
Input Impedance:
Microphone: 1.2k ohm transformer balanced
Line: 15k ohm electronically balanced
Output Impedance: <100 ohm electronically balanced
Gain:
Microphone: -15dB to +60dB
Line: -15dB to +10dB
Noise:
Microphone: <-128dBu ref 150 ohm (20Hz-20kHz)
Line: <-85dBu (EQ In, 20Hz-20kHz)
Maximum Levels:
Mic Input: +24dBu at all frequencies
Line Input: +24dBu at all frequencies
Distortion:
Mic Input: <0.05% T.H.D. (-50dBu input, +4dBu output)
Line Input: <0.05% T.H.D. (+4dBu input, +4dBu output)
Frequency Response:
Mic Input: ±1dB 20Hz to 20kHz
Line Input ±1dB 20Hz to 20kHz
Nominal Operating Level: +4dBu
Peak LED Threshold: +10dBu
In accordance with our policy of continuing product improvement, we reserve the right to alter
specifications without prior notice.
