Tridonic PRO Series - Electrical Values; Maximum Loading of Automatic Circuit Breakers; Insulation Matrix

www.tridonic.com
9
Subject to change without notice. Information provided without guarantee.
Data sheet 10/20-EM091-6
Emergency lighting units
EM converterLED
Automatic circuit breaker type B10 B13 B16 B20 C10 C13 C16 C20 Inrush current
Installation Ø 1.5 mm
2
1.5 mm
2
1.5 mm
2
2.5 mm
2
1.5 mm
2
1.5 mm
2
1.5 mm
2
2.5 mm
2
I
max
time
EM converterLED PRO MH/LiFePO4 50V 90 130 130 130 180 260 260 260 10 A 120 μs
5. Electrical values
5.1 Maximum loading of automatic circuit breakers
5.2 Insulation matrix
Mains Switched Live
Battery, LED, Test
switch, Indicator LED
DALI
Mains
– • • • •
Switched Live
• – • • •
Battery, LED, Test
switch, Indicator LED
• • • • – •
DALI
• • • –
• Represents basic insulation
• • Represents double or reinforced insulation
When using a non-SELV LED Driver insulate the battery, LED, test switch and indicator LED in the luminaire according to the
U-OUT rating of the LED Driver.
