Page 10
HF-2
PROGRAMMING THE UNIT
Enter the Programming Mode: Call the unit, then
press [✽{pppp}] ☎☎
[0{f}]☎☎ Set unit’s Gate Open time
[1{iiii}]☎☎ Set unit’s Site ID number
[2 then 1-0] ☎ [nnn nnn#] ☎☎ Set unit’s Auto dial
numbers
[3{pppp}]☎☎ Set unit’s Program Code
[5{r}]☎☎ Set Ring Count before auto answer
[6{d}]☎☎ Set Dial Mode‡
‡ Dial Mode
0 = Tone dial only
1 = Rotary dial only
2 = Tone dial with Secondary Relay pulse
3 = Rotary dial with Secondary Relay pulse
[7{x}]☎☎ Set Operation Mode, where x = :
0 = Standard mode
1 = Emergency mode
2 = Multiple HF-2’s share same phone line
4 = Ring Down mode (Seizes phone line, waits)
[8{lll}]☎☎ Set Call Length Time Limit
[9(tones)#] Echo Test.
[ ] then 1-0] Verifies primary or backup telephone
numbers
[#] Return to Normal Mode
Legend:
d Dial mode (0= Touch, 1= Rotary)‡
f Five second relay duration time (1, 2,…9)
iiii Site ID number (always use four digits)
lll Call Length Time in seconds (001, …999)
nnn nnnn Phone Number (up to 12 digits)
pppp Program Code
r Ring Count (1, 2, …9)
✽ The “star” key of the telephone
# The “pound sign” key of the telephone
☎ Tones returned by the unit
SECURITY DEPT. OPERATION
When Security personnel receive a call from the unit,
they press key [X] on their telephone to:
STANDARD MODE
[0,5] Cycle Primary Relay
[1,6] Cycle Secondary Relay
[2] Factory Tone Test (answer tone)
[7] Force disconnect (hang up)
[8] Extends current Call Timer 3 minutes
[9] Toggle on/off Secondary Relay (☎ = off, ☎☎ = on)
[#] Requests Site ID Number
[✽{pppp}] Enter Program Mode
General
Data between [ ] is a mandatory program key stroke sequence. Data between { } is to be supplied by the programmer.
Unit responses are shown between ( ).
CONDENSED GUIDE TO USE and PROGRAMMINGCONDENSED GUIDE TO USE and PROGRAMMING
CONDENSED GUIDE TO USE and PROGRAMMINGCONDENSED GUIDE TO USE and PROGRAMMING
CONDENSED GUIDE TO USE and PROGRAMMING
✽
