EZ-Guide 500 System Cabling Guide 29
Connecting to an EZ-Steer System 4
Q SNB900 to EZ-Guide 500 61158
R Radio antenna 22882-00
S N female to Rev POL TNC Male 62114
Item Connector description
1P2
2P1
3R2
4 Laptop connector (for firmware upgrade)
5 Alternate power connector
6S1
7P3
8P1
9S3
10 To power
Item Description Part number
