Trimble EZ-Guide 500 - EZ-Steer 500 System with Krohne Flow Meter

EZ-Guide 500 System Cabling Guide 73
Accessory Connections 8
EZ-Steer 500 system with Krohne flow meter
This figure shows how to connect the EZ-Steer 500 system to a Krohne flow meter:
Item Description Part number Item Description Part number
A EZ-Guide 500 lightbar 66100-xx B Krohne flow meter to
EZ-Guide 500 lightbar
78369
ESC
+ 7 . 184
0%
50
100
m
s
A
B
To Krohne
D-D+
