Trimble M3 Total Station User Manual

Trimble M3 Total Station User Guide 21
Overview of the Trimble M3 Total Station 2
4. Coordinates 1. Resection See Resection, page 74.
2. Known Station 1. Hz - known station setup by BS Azimuth input.
2. YX - Known station setup by XYZ to BS.
See , page 79.
3. Station elevation REM. See Station elevation, page 83.
4. Measure topo Eccentricity (softkey) - In/Out, Right/Left offset distance input,
height and frequency settings. See Eccentric measurement,
page 85.
Input dSD (softkey).
See Measure topo, page 83.
5. Stake Out 1. XY - stakeout by coordinate, 2D. See Stake out by coordinates
(XY or XYZ), page 87.
2. HD - stakeout by angle and distance, 2D. See Stakeout by angle
and distance (HD or HDh), page 89.
3. XYZ - stakeout by coordinate, 3D. See Stake out by coordinates
(XY or XYZ), page 87.
4. HDh - stakeout by angle and distance, 3D. See Stakeout by
angle and distance (HD or HDh), page 89.
5. RefLine 2D - stakeout points from a line defined by Sta and O/S.
See Stakeout by reference line, page 90.
6. DivLine 2D - stakeout points after dividing a line by equal
distances. See Stakeout by dividing line, page 91.
5. Setting - Instrument 1. Angle Set angle accuracy, display unit, VA reference and direction.See
Angle settings, page 34.
2. Distance Set distance accuracy and display unit. See Distance settings,
page 35.
3. Coord. System Set axis type and display order. See Coordinate system settings,
page 36.
4. Units Set temperature and pressure. See Units settings, page 36
5. Turn Off Set auto-power cut-off settings and sleep settings for the main
unit. See Turn Off settings, page 36.
6. Clock Set the built-in clock. See Clock settings, page 37.
7. Miscellaneous Set default input modes in the code and point name fields. See
Miscellaneous settings, page 37.
6. Settings - interface Set the recording format. See Configuring data recording and
external communication settings, page 38.
7. Data Transfer 1. MEM-Periph Download data.See Downloading internal memory to an office
computer, page 111.
2. Periph-MEM Upload data (coordinates).See Uploading data from an office
computer to the internal memory, page 113.
3. Upload Point List Upload point-number list. See Uploading a point name/number
list from the office computer, page 114.
4. Upload Code List Upload point-code list. See Uploading a point code list from the
office computer, page 114.
Menu item Sub-menu Description
