ASSEMBLY INSTRUCTIONS
STEP 3
Carefully turn sink right-side up, standing it upright.
Unscrew large 3-3/8” Nut from bottom of DRAIN ASSEMBLY (E). From inside SINK (A),
insert Drain through White Seal and opening at bottom.
From under SINK (A), first slide on Black Gasket and Paper Gasket then screw large 3-3/8”
Nut back on tightly. If necessary, use a pipe wrench to tighten.
Note: P-trap NOT included.
E
Optional replacement
with plumber’s putty
(not included)
Drain Assembly (E)
5
