Page 9
E Series Ethernet Radio – User Manual
Version 08-10
Part B – E Series Overview
Part Number Description
Duplexers
DUPLX450BR Duplexer BAND REJECT 400-520 MHz for
use with Base / Repeater / Links. For Tx / Rx
frequency splits >9MHz. (Fitted Externally
for a Link, Internally or Externally for Base /
Repeater)
DUPLX450BPC Duplexer BAND REJECT 400-520 MHz for
use with Base / Repeater / Links. For Tx / Rx
frequency splits <9MHz. (Fitted Externally
for a Link, Internally or Externally for Base /
Repeater)
DUPLX450BP Duplexer PSEUDO BAND PASS Cavity 400-
520 MHz for External use with Base / Repeater
/ Links.
Notes:
1. Frequencies must be specied at time of order.
2. Interconnecting (Feeder Tail) cables must be ordered
separately for Externally tted Duplexers.
Antennas
ANT450/9A Antenna Yagi 6 Element 9dBd Aluminium 400-
520 MHz c/w mtg clamps
ANT450/9S Antenna Yagi 6 Element 9dBd S/Steel 400-520
MHz c/w mtg clamps
ANT450/13A Antenna Yagi15 Element 13dBd Aluminium 400-
520 MHz c/w mtg clamps.
ANT450/13S Antenna Yagi 15 Element 13dBd S/Steel 400-
520 MHz c/w mtg clamps.
ANTOMNI/4 Antenna Omnidirectional Unity Gain Side Mount
Dipole 400-520 MHz c/w galv. clamp
ANT450/D/N Antenna Omnidirectional Unity Gain Ground
Independent Dipole 400-520 MHz c/w 3m
cable, mounting bracket & N connector
ANT450/6OM Antenna Omnidirectional 6dBd 400-520 MHz
c/w mtg clamps
ANT450/9OM Antenna Omnidirectional 9dBd 400-520 MHz
c/w mtg clamps
Note:
1. Frequencies must be specied at time of order.
Power Supplies
PS13V82A Power Supply 13.8V 2A 240VAC
PS13V810A Power Supply Switch Mode 240VAC 13.8V 10A
for Base Stations – Battery Charge Capability
Part Number Description
RF Cables and Accessories
NM/NM/TL23 Feeder Tail - N Male to N Type Male 50cm fully
sweep tested RG-223
NM/NM/TLL23 Feeder Tail - N Male to N Type Male 1 metre
fully sweep tested RG-223
RFCAB5M 5.0m RG-58 type Antenna Feeder Cable
terminated with N type Male Connectors
RFCAB5M2 5.0m RG-213 type Antenna Feeder Cable
terminated with N type Male Connectors
RFCAB10M 10.0m RG-213 type Antenna Feeder Cable
terminated with N type Male Connectors
RFCAB20M 20.0m RG-213 type Antenna Feeder Cable
terminated with N type Male Connectors
RFCAB20M4 20.0m LDF4-50 type (1/2” foam dialectric)
Antenna Feeder Cable terminated with N type
Male Connectors
LGHTARRST Lightning Surge Arrestor In-line N Female to N
Female
Multiplexers
MSR/9 Multiplexer/Stream Router – 9 Port with RS-232
I/faces, Manual and software.
Network Management Diagnostics
DIAGS/E Network Management and Remote Diagnostics
Facilities per Radio – E Series Ethernet
DIAGS/EH Network Management and Remote Diagnostics
Facilities – E Series for EH45e
Software
TVIEW+ Conguration, Network Management and
Remote Diagnostics Software
Other
ERFD45e ER45e Conversion to Full Duplex Operation (N
Type – Tx Port, SMA - Type Rx Port)
Note: Requires external duplexer
ERFDTRAY 19” Rack Tray for Mounting of ER45e Full
Duplex Radio and External Band Reject
Duplexer
Standard Accessories
