18
HANDLEBAR
- Using a 6 mm Allen wrench loosen the bolt at the front of the stem.
IMPORTANT: do not loosen the bolts on the side of the stem.
- Grasp the stem of the handlebar and rotate to the desired angle.
- Re-tighten the handlebar bolt at the front of the stem and check the handlebar is
securely attached and cannot move.
- Once you have adjusted the angle of the handlebar check the angle of the cables to be
sure they are facing forward.
- Unlock the quick-release lever.
- Adjust the stem height up or down.
- Lock the quick-release lever.
ADJUSTING THE STEM ANGLE ADJUSTING THE STEM HEIGHT
19
