Triple S Wildcat - Page 11

DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1
VV68104TP HANDLE / CORD WRAP
1
2
VV68201-2 COVER, RECOVERY TANK
1
3
VF83109-7 HOOK
2
4
VV20291 WASHER, LOCK, M4
6
5
VV13667 SCREW, PH, M4 X 8
6
6
VF13614 WASHER, PLAIN, M6
10
7
VV13607 WASHER, LOCK, M6
12
8
VF14200 SCREW, PH, M6 X 16
12
9
VV68201-1 RECOVERY TANK
1
10
VV68201-3 ELBOW, HOSE BARB
1
11
VV68115 GASKET, RECOVERY TANK
1
12
VV68301-2 COVER, SOLUTION TANK
1
13
VV68130 WASHER, SEAL
1
14
VV20274A WASHER, PLAIN, M14
1
15
VV68135 BARB, HOSE
1
16
VF46400 CLAMP
4
17
VV68141 HOSE
1
18
VV68301-1 SOLUTION TANK
1
19
VV68113 FILTER, VAC MOTOR
1
20
VV68114 SCREEN
1
21
VV68111 GASKET, SOLUTION TANK, 4"
1
22
VV68127TP COVER
2
23
VV68105TP WHEEL, 8"
2
24
VF14301 SCREW, M4 X 12
2
25
VV68101 HOUSING
1
26
VV68119 COLLAR
2
27
VF13525 SCREW, M6 X 8
2
28
VV13665 NUT, M10 X 1
2
29
VV68143 HOSE
2
30
VF14005 NUT, M10
1
31
VF13518 WASHER, LOCK, M10
1
32
VF13537 WASHER, PLAIN,M10
5
33
VV68118 AXLE
1
34
VV20501 SCREW, PH, M5 X 14
7
35
VV13601 WASHER, LOCK, M5
7
36
VV13662 WASHER, PLAIN, M5
7
37
VV68133TP DECAL, SERIAL
1
38
VV13635 SCREW, PH, M5 X 20
4
39
VV68132 WASHER, SEAL
3
40
VV68128 HOSE BARB
2
41
RD60128 ELBOW, HOSE BARB
2
42
VF13634 BOLT, M10 x 30
1
43
RD10461 SCREEN
1
44
VV68142 HOSE
1
45
VV80208 COUPLER,QUICK CONNECT
1
46
VF83109 CATCH
1
47
VV68308 LABEL, DRAINING
1
48
VV68145 SEALER
1
49
VV60220S1 SCREW,M6 X 16
2
50
VF13533 WASHER, PLAIN, M6
2
51
VV68136TR LOGO
2
9
