Triple S Wildcat - Page 13

DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1 VV68112 GASKET, VAC MOTOR, 5.75"
1
2 ZD49000A VACUUM MOTOR, 110V
1
3 VV68116 SPACER, VAC MOTOR
4
4 VV68110 GASKET, VAC MOTOR
1
5 VV68109 MOUNTING PLATE, VAC MOTOR
1
6 VV68117 SPACER, VAC PLATFORM
4
7 VV68120 GASKET, BAFFLE
1
8 YQ60504 RING
1
9 VV13662 WASHER, PLAIN, M5
32
10 VV13601 WASHER, LOCK, M5
28
11 VF14214 SCREW, PH, M5 X 8
12
12 VF83109 CATCH
1
13 VF13666 SCREW, PH, M4 X 6
2
14 VV20291 WASHER, LOCK, M4
2
15 VV68107 BAFFLE & REAR PANEL
1
16 VV20501 SCREW, PH, M5 X 14
16
17 RD60128 BARB, HOSE
2
18 RD50258 DIODE ASSEMBLY
1
19 RD50264 PUMP, 110V
1
20 VV13633 NUT, M5
8
21 VV68126 BRACKET, PUMP MOUNTING
2
22 VV68108-2 CONNECTOR
2
23 VV68108-1 BOTTOM MOUNT PLATE
1
24 VV68106 MOUNTING PLATE, SWITCH ASSEMBLY
1
25 VA91346 SWITCH ASSEMBLY
1
26 VV30183 POWER CORD
1
27 VF99008B CORD STRAIN RELIEF
1
28 VV20509 PH SCREW, M5X10
4
29 VV68123 CASTER, 1.5"
1
30 VV68183 SPONGE
1
11
