10
Specifications
Connectors
Input (3x) HDMI (Female)
Output HDMI (Female), DB9 (Female)
Video
Maximum Resolution 4096 x 2160 @ 60 Hz
Color Depth 36-bit Deep Color (12 bits per channel)
Video Amplifier Bandwidth 10.2 Gbps / 300 MHz
Environmental
Operating Temperature 32° to 140°F (0° to 60°C)
Storage Temperature -4° to 158°F (-20° to 70°C)
Relative Humidity 0% to 95%, Non-Condensing
Physical
Unit Dimensions (H x W x D) 0.8 x 6.3 x 2.0 in. (20 x 160 x 51 mm)
Unit Weight 0.54 lb. (240 g)
Power Requirements
External Power Supply 5V 1A
Power Consumption (Max) 5W
18-01-070-933768-EN.indd 10 2/6/2018 3:53:04 PM
