4
Both extender kit models include mounting hardware that allows for a
variety of mounting methods. The following images illustrate how the
included mounting brackets can be attached for different installations.
Note: The model shown in the below images is for illustrative purposes only. Your
product may vary by model number, size or port orientation. The mounting options
for all over IP units are the same.
19” Rack-mount Pole-mount
Wall-mount
Mounting Instructions
