7
10. Optional Caster and Handle Accessory
9. Specifications
Model CS16AC/CS16ACW CS32AC/CS32ACW
Cabinet Dimensions (H x W x D) 21.6 x 23.63 x 21.6”
(549 x 600 x 549 mm)
35.6 x 23.6 x 21.6“
(905 x 600 x 549 mm)
Unit Weight 55 lb. (25 kg) 96 lb. (43.5 kg)
Load Capacity* 200 lb. (90 kg) Stationary or Rolling 250 lb. (113 kg) Stationary or Rolling
Cabinet Mounting Depth
(Adjustable)
3” to 20.5”
(76 to 521 mm)
3" to 20.5"
(76 to 521 mm)
AC Receptacles 16 x 5-15R 32 x 5-15R
Power Requirement Input: 120V AC, 50/60 HZ, 12 Amps Input: 120V AC, 50/60 HZ, 12 Amps
Operating Temperature 32° to 104° F
0° to 40° C
32° to 104° F
0° to 40° C
Operating Humidity 5 to 95% RH, Non-Condensing 5 to 95% RH, Non-Condensing
Number of AC Charger Units 1 2
AC Charger Dimensions per Unit
(H x W x D)
2.25 x 19 x 4”
(57 x 483 x 241 mm)
2.25 x 19 x 4”
(57 x 483 x 241 mm)
Enclosure Material Metal Metal
Regulatory Approvals UL 60950, NOM (Mexico) and RoHS UL 60950, NOM (Mexico) and RoHS
*Full wall-mount load capacity requires a mounting surface capable of bearing the full load of the tablet charge and sync station and all connected components. Rolling applications
require optional CSHANDLEKIT accessory kit. Specifications may be subject to change without further notice.
For applications requiring extra mobility, an
optional caster and handle accessory kit
(Model: CSHANDLEKIT) contains two swivel/
locking casters, two swivel-only casters and a
handle that attaches to the top of a charging
station unit. For further installation instructions,
refer to the manual included with the
CSHANDLEKIT.
