Diag. Part No. Description Qty Supplied Comments
Ref. as Spare Part
Specifications:
Packed weight: 9.34kg Dimensions: 695 x 445 x 60mm Volume: 0.018m
3
Paint: Epoxy powder coat (oven cured) Table : Telecom Gold Fence: Charcoal Grey
- PUA208 Packing Carton 1
- PUA254 Packing List 1
- PUA211 Instruction Manual 1
A RTA003 Table Top 1 Includes nylon insert set &
slide catches.
B RTA054 Main Fence 1
C RTA052 Front Fence 1
D RTA049 MDF Sub-fence (300 x 50 x 16mm) 2
E RTA212 Guard Housing 1
F RTA211 Safety Guard 1
G CMA033 Hose Adaptor 1
H CMA034 Vacuum Hose 1 Length 1.5 metre
I CMA032 Hose Nozzle 1
J RTA017 Router Slide Plate 1
K RTA067 Router Alignment Disc 1 Includes 1/4” & 3/8” bushes
L & N WCA125 T-handle & Clamping Bolt Set 2
M RTA055 Bridge Washer 1
O RTA024 Fence flat head coach bolt 1
P - 7mm x 19mm Washer 3 Available in Fastener Bag
Q CPA096 Tri-knob (6mm) 1
R - 6mm x 25mm coach bolt 1
S & T - 4x10mm CSK Screw & 4mm Flange Nut 2
U - 16mm self tapping screw 4
V RTA041 Table insert set (3 pieces) 1
W RTA050 Table Slide Catches 2 Includes pop rivets & bushes
X RTA213 Anti-kickback Fingers 2
Y WCA101 Bearings 4 Includes bolts & nuts
Z RTA027 Router Clamping Brackets Set 4 Includes bolts, nuts & washers
- RTA061 Fastener Bag Complete 1 Contains Router Clamps
(RTA027) & fence hardware
- RTA062 Fence Fastener Bag 1
- AJA002 Jigsaw Clamp Set 1 Included with AJA001* Slide Plate
FASTENERS NOT
SUPPLIED SEPARATELY
a
1
/
4
” x 2” coach bolt 4
b
1
/
4
” x
5
/
8
” washer 4
c
1
/
4
” spring washer 8
d
1
/
4
” hex nut 4
e
1
/
4
” x
3
/
4
” washer 4
f
1
/
4
” wing nut 4
g Locator Bracket 4
h Top Clamp 4
* An optional mounting plate with jigsaw clamps (part no. AJA001) is available for separate sale.
See new products pricing.
Router / Jigsaw Table Series 2000 - RTA200
Suits MK3 & Series 2000 Workcentres and all Router / Jigsaw Stands.
Available in RTA027
Available in Fastener Bag
