Triton INSTAFLOW User Manual

INSTAFLOW
5
ELECTRICAL
Nominal power - rating at 240V Nominal power - rating at 230V
5.4kW – (25A MCB rating) 4.9kW – (25A MCB rating)
PLUMBING
Supply Source Mains pressure cold water only
Minimum running pressure to the inlet
of the water heater for full performance
40kPa (0.4 bar)
Maximum static pressure 600 kPa (6 bar)
Maximum inlet temperature 25°C
Minimum inlet temperature 5°C
Inlet connection ½” BSP male thread
Outlet connection ½” BSP male thread
PRODUCT FICHE
Model 5.4kW
Load Prole XXS
Energy Efciency Class A
Energy Efciency (%) 39.0%
Annual Electricity Consumption kWh 473
Sound Power Level dB 15
TECHNICAL DATA
Protection class IPX4
Dimensions & weight 230x130x75mm / 1.5kg
Minimum water ow 2.0 lpm
SPECIFICATIONS
