Thank you for purchasing this Triton tool. Please read these instructions: they contain information necessary for safe and
effective operation of this product. This product has a number of unique features and, even if you are familiar with similar
products, reading the instructions will help you get the full benefit of its unique design. Keep these instructions close to hand
and ensure all users of this tool have read and fully understand them.
Contents / Specifications
Specifications 2
Symbols 3
Features 4
Safety Instructions 5
Preparation 8
Operating Instructions 10
Saw Bench Guide 11
Replacing the Saw Blade 11
Maintenance 11
Troubleshooting 12
Warranty 14
Model no: TA235CSL
Voltage: EU - 220V - 240V AC, 50/60Hz, 10.5A
SA - 220V - 240V AC, 50/60Hz, 10.5A
AU - 220V - 240V AC, 50/60Hz, 10.5A
USA - 120V AC, 60Hz, 15A
Input power: 2300W / 3.08hp
No load speed: 4500min
-1
Blade size: 235mm / 9
1
⁄4"
Blade arbor: 30mm / 1.1"
Blade teeth: 40 TCT
Bevel adjustment: 0° to 47°
Positive bevel stops: 0°, 15°, 22.5°, 30° and 45°
Cutting capacity at 90°: 82mm / 3.2"
Cutting capacity at 45°: 58mm / 2.2"
Insulation: Double insulated
Net weight: 7.4kg / 16.3lbs
Sound pressure level: 98.1dB(A)
Sound power level: 109.1 dB(A)
Typical weighted vibration: 2.969m/s
2
Protect your hearing
Always use appropriate hearing protection when tool noise exceeds 85dB.
