STEP 8
PARTS REQUIRED:
2 pcs - P6 Upper Tube
Attach Backboard assembly from STEP 7 to Frame assembly from STEP 5 as shown in FIGURE 8.
Attach P6 Upper Tubes to P7 Backboard assembly using Spring Lock as shown in FIGURE 8.
FIGURE 8
Spring Lock
NOTE :
IF BACKBOARD TUBES DO NOT
WANT TO ATTACH TO THE FRAME
ASSEMBLY -- SIMPLY LOOSEN THE
4 BOLTS AND NUTS AT THE ENDS
OF THE HORIZONTAL TUBES IN
THE BACKSIDE OF THE LOWER
FRAME TO CORRECTLY ADJUST
THE CONNECTING TUBES .
RETIGHTEN THE 4 BOLTS AND
NUTS WHEN BACKBOARD
ASSEMBLY IS CORRECTLY
ATTACHED .
P6
Spring Lock
