PARTS IDENTIFIER (Not to Scale)
P11 - Mechanical
Scoring Arm
(2 pcs)
P12 - Rim (2 pcs)
P13 - Rim Net
(2 pcs)
P14 - Rim Support
Plate (2 pcs)
P18 - Mechanical Scoring
Arm Support Plate (2 pcs)
ACCESORY IDENTIFIER (Not to Scale)
A1 - Air Pump
with Needle
(1 pc)
A2 - Basketball (4 pcs) A3 - A/C Adapter (1 pc)
P15 - Locking Pin
(2 pcs)
Note: This is a special rim net
designed to avoid entanglement
3 pcs AA Batteries Required ,
Not Supplied
with the mechanical scoring arm.
Note: This is a special rim
designed to avoid entanglement
with the mechanical scoring arm.
P16 - Scoring
Control Box
Wire (1 pc)
P9 - Electronic
Scorer (1 pc)
P10 - Electronic
Scorer Face Plate
(1 pc)
P17 - Control Box
(1 pc)
