Triumph DAYTONA 650 User Manual

!!
!
General Information
Page 18
INSTRUMENT PANEL LAYOUT
1. Tachom e te r 8. Engine Manageme nt Malfunction
2. Tachometer ‘Red Zone’ Indicator Light
3. Speedometer 9. Low Fuel Level Indicator Light
4. Odometer/Trip Meters/Clock Display 10. Neutral Indicator Light
5. Select/Reset Buttons 11. High Beam Indicator Light
6. Coolant Temperature Display 12. Low Oil Pressure/High
7. High Coolant Tempe rature/ Coolant Temperature Warning Light
Low Oil Pressure Warning Messages 13. Turn Indicator light
SPEEDOMETER and ODOMETER
The digital speedometer indicates the road
speed of the motorcycle. The read-out
displays the motorcycle road speed in
increments of one kilometer (or mile) per
hour.
In the speedometer face is the electronic
odometer, two trip meters and the clock. For
details of the operation of the odometer , trip
meters and clock, please refer to the
following pages.
TACHOMETER
The tachometer shows the engine speed in
revolutions per minute -- rpm (r/min). On the
right side of the tachometer face is the ‘red
zone’. Engine rpm (r/min) in the red zone is
above maximum recommended engine
speed and is also above the range for best
performance.
CAUTION: Never allow
engine RPM to enter the ‘red
zone’ as severe engine damage may
result.

Triumph DAYTONA 650 Specifications

General

Displacement	646 cc
Transmission	6-speed
Rear Brakes	Single 220mm disc, single-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Fuel System	Multipoint sequential electronic fuel injection
Engine Type	Liquid-cooled, DOHC, inline 4-cylinder
Max Torque	68 Nm @ 11, 000 rpm
Frame	Aluminum
Rear Suspension	Monoshock with adjustable preload
Front Brakes	Twin 308mm floating discs, 4-piston calipers
Seat Height	825 mm
Dry Weight	165 kg
Ignition	Digital
Final Drive	Chain
Length	2, 060 mm
Wheelbase	1395 mm
Fuel Capacity	17.5 liters (4.6 US gal)
