1120
Front ABS Pulser Ring – Inspection
1. Check the pulser ring for damaged, missing or cracked teeth or distortion. Renew the
pulser ring as necessary.
Front ABS Pulser Ring – Installation
Before starting work, make sure the motorcycle is stabilised and adequately
supported. This will help prevent it from falling and causing injury to the operator or
damage to the motorcycle.
1. Fit the front brake disc and pulser ring (see Front Brake Disc - Installation).
Rear ABS Wheel Speed Sensor – Removal
Before starting work, make sure the motorcycle is stabilised and adequately
supported. This will help prevent it from falling and causing injury to the operator or
damage to the motorcycle.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Rear Wheel - Removal
1. Release the three fixings and detach the hugger from the swinging arm.
