Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Fit the camshaft drive chain tensioner blade with the hardened washer as noted for
removal. Tighten the fixing to 18 Nm.
1. Fixing
2. Tensioner blade
Perform the following operations:
• Camshaft Drive Chain - Installation
• Camshaft - Installation
• Plenum - Installation (All Markets Except US) or Plenum - Installation (US
Markets Only)
• Clutch Cover - Installation
• Thermostat - Installation
