Maintenance
129
• Fill the final drive unit with fully
synthetic 75W/90 hypoid oil that
meets specification API Service Level
GL5, such as Castrol SAF-XO fully
synthetic hypoid oil, until the level of
oil inside the final drive unit is level
with the bottom of the filler.
• Refit the filler level plug and tighten
to 25 Nm.
Brakes
Brake Wear Inspection
B00124
1
2
1. Brake pads
2. Minimum thickness line
Brake pads must be inspected
in accordance with scheduled
requirements and replaced if worn to, or
beyond the minimum service thickness.
If the lining thickness of any pad (front
or rear brakes) is less than 1.5 mm
(0.06 in), that is, if the pad has worn
down to the bottom of the grooves,
replace all the pads on the wheel.
