Parts Identification
18
Parts Identification
Tiger 900 Rally and Tiger 900 Rally Pro
2
3
4
5
16
15 14 12 1117
1
13
7
86 9 10
1. Headlight
2. Front direction indicator
3. Electrical accessory socket (front)
4. Fuel tank and fuel filler cap
5. Tool kit (under the rider seat)
6. Battery and fuse boxes (under the rider
seat)
7. Seat lock
8. Electrical accessory socket (rear if fitted)
9. USB socket (under the passenger seat)
10. Heated rear seat switch (if fitted)
11. Rear wheel adjuster
12. Drive chain
13. Centre stand (if fitted)
14. Side stand
15. Gear change pedal
16. Front brake caliper
17. Front brake disc
