Triumph Tiger 900 - Odometer and Speedometer; Tachometer

General Information
44
Odometer and Speedometer
The odometer shows the total distance
that the motorcycle has travelled. The
odometer is only shown in the Service
information tray.
The speedometer indicates the road
speed of the motorcycle.
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
52
FE
CH
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
SERVICE
Recommended by
03/2020
or in
460 miles
ODO: 0001234 mi
1
2
1. Odometer
2. Speedometer
Tachometer
The tachometer shows the engine
speed in revolutions per minute–rpm
(r/min). At the end of the tachometer
range there is the red zone. Engine
speeds in the red zone are above
maximum recommended engine speed
and are also above the range for best
performance.
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
6400
52
FE
CH
21.5 10:55
AM
C
o
x1000rpm
RPM
SET 100
9
ABS
+
MPH
TACHOMETER
1
2
1. Engine speed (rpm) shown in a numerical
format
2. Engine speed (rpm) shown in a graph
format
