General Information
77
Note
For all motorcycles models without
the Tyre Pressure Monitoring System
(TPMS) fitted as standard, it is available
as an accessory fitted item. It must
be fitted by your authorised Triumph
dealer. The TPMS display on the
instruments will only be activated when
the system has been fitted.
Tyre Pressure Warning Light (if
TPMS is fitted)
Warning
Stop the motorcycle if the tyre
pressure warning light illuminates.
Do not ride the motorcycle until the
tyres have been checked and the tyre
pressures are at their recommended
pressure when cold.
The tyre pressure warning
light works in conjunction
with the Tyre Pressure
Monitoring System, see
page 76.
The warning light will only illuminate
when the front or rear tyre pressure is
below the recommended pressure. It will
not illuminate if the tyre is over inflated.
When the warning light is illuminated,
the Tyre Pressure display will show
which tyre is the deflated tyre. It will
also show the tyre pressure.
36 28
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
52
REAR FRONT
psipsi
FE
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
TYRE PRESSURE
1 42 3
1. Rear tyre pressure indicator
2. TPMS warning light
3. Low front tyre pressure warning shown
4. Front tyre pressure indicator
The tyre pressure at which the warning
light illuminates is temperature
compensated to 20°C but the numeric
pressure display associated with
it is not (see page 154). Even if the
numeric display seems at or close to
the standard tyre pressure when the
warning light is on, a low tyre pressure
is indicated and a puncture is the most
likely cause.
