Specifications
192
Fuel System Tiger 900 Rally and Tiger 900 Rally Pro
Type Electronic Fuel Injection
Injectors Solenoid Operated
Fuel Pump Submerged Electric
Fuel Pressure (nominal) 3.5 bar
Fuel Tiger 900 Rally and Tiger 900 Rally Pro
Type 91 RON unleaded
Tank Capacity (motorcycle upright) 20.0 litres
Ignition Tiger 900 Rally and Tiger 900 Rally Pro
Ignition System Digital Inductive
Electronic Rev Limiter 10,000 r/min
Spark Plug NGK CR9EK
Spark Plug Gap 0.7 mm
Gap Tolerance +0.05/-0.1 mm
Transmission Tiger 900 Rally and Tiger 900 Rally Pro
Transmission Type 6 Speed, Constant Mesh
Clutch Type Wet, Multi-Plate
Primary Drive Ratio 1.652:1 (76/46)
Gear Ratios:
1st 2.615:1 (34/13)
2nd 1.857:1 (39/21)
3rd 1.500:1 (36/24)
4th 1.286:1 (27/21)
5th 1.107:1 (31/28)
6th 0.967:1 (29/30)
Final Drive Tiger 900 Rally and Tiger 900 Rally Pro
Final Drive Chain
Final Drive Ratio 3.125:1 (50/16)
Chain Type RK O-ring
Number of Links 122
20 Link Length 319 mm
Drive Chain Vertical Movement Range 30–40 mm
