Parts Identification
20
Rider View Parts Identification
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
32
FE CH
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
SERVICE
Recommended by
03/2020
or in
460 km
ODO: 0001234 mi
16 15 14
123
78
10
1113 12
45 6
17
9
1819
1. Clutch lever
2. Headlight dip switch
3. Heated seats switch (if fitted)
4. Fog lights switch (if fitted)
5. Cruise control adjust switch
6. TFT instrument display
7. Front brake fluid reservoir
8. Hazard warning light button
9. Front brake lever
10. Engine start/stop button
11. HOME button
12. Ignition switch
13. Electrical accessory socket
14. MODE button
15. Joystick button
16. Direction indicator switch
17. Horn button
18. Daytime Running Lights (DRL) (if fitted)
19. Heated grips switch (if fitted)
