General Information
67
Tyre Pressure Monitoring System
(TPMS) (if fitted)
Warning
Stop the motorcycle if the tyre
pressure warning light illuminates.
Do not ride the motorcycle until the
tyres have been checked and the tyre
pressures are at their recommended
pressure when cold.
The Tyre Pressure Monitoring System
(TPMS) information tray is with the
Service information tray.
To view the Tyre Pressure Monitoring
System (TPMS):
• Push the joystick down/up and
scroll the Service information tray.
• Select Tyre Pressure by pushing the
joystick left/right.
The Tyre Pressure Monitoring System
(TPMS) information tray shows the front
and rear tyre pressures.
36 28
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
52
REAR FRONT
psipsi
FE
CH
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
TYRE PRESSURE
1 42 3
1. Rear tyre pressure indicator
2. Tyre pressure warning light
3. Low front tyre pressure warning shown
4. Front tyre pressure indicator
Tyre Pressure Warning Light
The tyre pressure warning light will only
illuminate when the front or rear tyre
pressure is below the recommended
pressure. It will not illuminate if the tyre
is over inflated.
Front Tyre Pressure Indicator
This shows the current front tyre
pressure.
Rear Tyre Pressure Indicator
This shows the current rear tyre
pressure.
Low Tyre Pressure
The front or rear tyre will be highlighted
on the motorcycle image to indicate
that the tyre pressure is below the
recommended pressure.
For more information on TPMS and tyre
pressures, see page 155.
Screen Contrast
The Contrast information tray allows the
display screen contrast to be adjusted.
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
52
FE
CH
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
SELECT
CONTRAST
AUTO LOWHIGH
1 32
1. High contrast option
2. Auto contrast option
3. Low contrast option
