General Information
86
Passenger Seat Removal
To remove the passenger seat:
• Insert the ignition key into the seat
lock, see page 85.
• Turn the ignition key anticlockwise
while pressing down on the rear of
the seat. This will release the seat
from its lock and allow it to be slid
rearwards.
• If fitted with heated seats, rotate
the passenger seat and rest it on
the rider's seat. Disconnect the
heated seat’s electrical connector.
• Remove the seat from the
motorcycle.
3
1
2
1. Electrical connector
2. Clip
3. Heated passenger seat
Passenger Seat Installation
2
2
1
1
3
1. Passenger seat brackets
2. Locating feature
3. Rider's seat mountings
To install the passenger seat:
• Reconnect the heated seat’s
electrical connector (if fitted).
• Push down firmly on the rear of the
rider seat and hold.
• Engage the seat's two brackets into
the locating feature.
• Press down at the rear to engage in
the seat lock.
