WARNING – To prevent risk of electrical shock, connect this system only to a properly
grounded, grounding-type power supply receptacle that is protected by a Ground Fault
Circuit Interrupter. Pull plug before servicing or replacing lamp. Keep all connections
dry and off the ground. Do not touch plug with wet hands.
WARNING – Read manual before installing or servicing this system. Only authorized
personnel possessing a strong understanding of this system should attempt to replace
lamp or service this system.
SAFETY
Attention!
WARNING – Do not look directly at UV lamp when it is operating. The light emitted by
the lamp will cause serious eye damage and burn unprotected skin.
NSF information pertains to TrojanUVMax™ Pro7 and Pro15 models
This Class A system conforms to NSF Standard 55 for the disinfection of microbiologically contaminated water
that meets all other public health standards. The system is not intended for treatment of water that has an obvious
contamination source, such as raw sewage; nor is the system intended to convert wastewater to microbiologically
safe drinking water. The system is intended to be installed on visually clear water (not coloured, cloudy, or turbid
water). If this system is used for the treatment of surface waters a prefilter found to be in compliance for cyst
reduction under ANSI/NSF Standard 53: Drinking Water Treatment Units - Health Effects shall be installed
upstream of the system.
NSF Standard 55 defines waste water to include human and/or animal body waste, toilet paper, and any other
material intended to be deposited in a receptacle designed to receive urine and/or feces (black waste); and other
waste materials deposited in plumbing fixtures (gray waste).
System tested and certified
by NSF International
against ANSI/NSF
Standard 55 for disinfection
performance, Class A.
Product Specifications
MODEL A B C D E F Pro7 Pro15
Flow Rates
0-3 GPM* 2-5 GPM* 5-14 GPM* 5-14 GPM* 8-28 GPM* 13-47 GPM* 8.2 GPM*** 17.8 GPM***
0-11 LPM 7-19 LPM 19-53 LPM 19-53 LPM 30-106 LPM 49-178 LPM 31 LPM 67.4 LPM
Audible/Visual Lamp
Failure Alarm
✓✓✓✓✓✓✓✓
Alarm Reset — — —
✓✓
✓
✓✓
Elapsed Time Meter — — — ✓✓✓
✓✓
Lamp Replacement
Reminder — — — ✓✓✓
✓✓
Electropolished Exterior — — — ✓✓✓
✓✓
Dry Contacts — — — ✓✓✓
✓✓
UV Intensity Monitor — — — D Plus E Plus F Plus
✓✓
Remote options cord — — — Optional Optional Optional Optional Optional
Solenoid (shut-off valve)** — — — Optional Optional Optional Optional Optional
Dynamic Flow Restrictor — — — — — —
✓✓
Water Chamber Material 304 SST 304 SST 304 SST 304 SST 316 SST 316 SST 316 SST 316 SST
Inlet/Outlet 3/8” FNPT 3/4” NPT 3/4” NPT 3/4” NPT 1” NPT 1” NPT 1” NPT 1” NPT
* See sizing charts for details. Flow rates shown are at 85% UVT.
** Remote options cord needed for solenoid valve or remote alarm connection.
*** NSF Standard 55 Class A certifies flow rates shown. The temperature of the flowing water being treated must be between
1
0
C and 35
0
C (33.8
0
F to 95
0
F).
NOTE – Maximum pressure rating is 125 PSI (861.8 kPa)
