NO. DESCRIPTION Q'TY NO. DESCRIPTION Q'TY
1 MAIN FRAME 1 15 NOT APPLICABLE ON THIS MODEL 1
2 FRONT STABILIZER 1 16
DOMED HEAD SOCKET BOLTS
(M8 X 15MM) 3
3 REAR STABILIZER 1 17 CURVED WASHER 3
4 SQUARE HEAD BOLT M8*15MM 4 18 SADDLE ADJUSTING KNOB 1
5 FLAT WASHER 4 19 HANDLEBAR 1
6 END CAP (PRE-ASSEMBLED) 4 20 HANDLEBAR GRIP(PRE-ASSEMBLED) 1 PAIR
7 DOMED NUTS M8 4 21 HANDLEBAR LOCKING KNOB 1
8 SADDLE 1 22 PEDALS R & L 1 PAIR
9 SADDLE STEM 1 23 PROGRAMMALBE COMPUTER 1
10 LOWER STEM 1 23a
COMPUTER & SCREWS
(PRE-ASSEMBLED ON COMPUTER)
4
11
NUT & WASHER
(PRE-ASSEMBLED ON SADDLE) 3 24
HAND GRIP PUSLE SENSOR PADS
(PRE-ASSEMBLED)
2
12 HANDLE BAR STEM 1 25 CHAIN COVER, L 1
13 LOWER FLAT CABLE (to servo motor) 1 26 CHAIN COVER, R 1
14
UPPER CABLE(to programmable
computer)
1 27 MULTI SPANNER 1
S
S
T
T
E
E
P
P
2
2
.
.
Fix the saddle (8) on the saddle stem (9) with
pre-attached nuts and washers (11).
Insert the assembled saddle stem (9) into lower
stem (10) and adjust the saddle stem to desired
height and secure with saddle adjusting knob
(18).
N
N
O
O
T
T
E
E
!
!
Before exercising, check the knob being
tightened completely for safety.
S
S
T
T
E
E
P
P
1
1
.
.
Place the front stabilizer (2) and rear
stabilizer (3) to the main frame (1) then
fix it in place with the bolts (4), washers
(5) and nuts (7) in accordance with the
directions of the drawing.
◆
◆
A
A
S
S
S
S
E
E
M
M
B
B
L
L
I
I
N
N
G
G
S
S
T
T
E
E
P
P
S
S
◆
◆
