CHAPTER3INSTALLATION,DISMANTLING,STORING


3.1 INSTALLATION
Hydraulichammerisconnectedtotheexcavatorwithtwooilhosesandtwopins.

 Lowerdowntheexcavatorarmslowly,alignthepinholes,andfixthepinandpinstopper.Operatethebucketcylinder,so
astofixtheotherpin.

 Removetheend
capsofoilhoses,makesurethehosesclean.Connecttothehammeratoneendandtotheexcavator
pipelineattheotherend.Finally,openuptheStopValveontheexcavatorarm.


3.2 DISMANTLING
ShutofftheStopValveontheexcavatorarm.RemovethetwoOil
Hosesfromexcavatorpipeline.RemovethetwoPinsfrom
hammer shell. Excavator Arm goes up slowly, and then the Hammer will be free. Fasten the End Caps to the hammer and
excavatorpipelinetopreventdirt.


3.3 STORING
IftheHammernotbeusedtemporarily,pleasekeepitwell
asperthefollowinginstructions:
Removethechisel.EmptytheN2chamber,andstrikepistonbacktocylinder.LubricatetheFrontHeadbygrease.

PlaceHammeroncrossties,coveredbyraincoat;orindoorwarehoused.














Ifslowingdowntheengine,itwillbemucheasiertoalignthepinholes.
Afterloosingendcapsofoilhoses,pistoncangobackeasily.
