Trotec BE20 User Manual

6 EN
voltage detector BE20
Technical data
Parameter Value
Voltage indication 12/24/36/50/120/230/400/690 V AC/DC
Voltage detection automatically
Display tolerance -30% to 0% of the displayed value
Polarity indicator +/ -/~
Display delay <0.1sLED
Frequency range 50 / 60Hz
Power input appro. 2.1W for 600V
Current consumption l
s
<0.2A
Maximum permissible
measuring time for
voltages
duty cycle= 30s
Rest period between
voltage detections
10minutes
LED display from > 8V AC/DC
Operating temperat-
ure
-10 °C to +55 °C
Relative humidity 85%max.
Overvoltage category CAT III– 600V
Type of protection IP64
Dimensions
(lengthx widthx
height)
240x 40x 78mm
Battery 2 x 1.5 V AAA
Weight 237 g
Unipolar phase testing
Voltage range 100 to 690VAC
Frequency range 50/60Hz
Continuity test
Measuring range <300kΩ
Test current <5µA
Overvoltage protection 690VAC/DC
Phase sequence indicator
Voltage range 100to400V
Frequency range 50/60Hz
Measuring principle double-poleandcontact-
electrode
Scope of delivery
• 1xVoltage detectorBE20
• 1x Manual
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
When transporting the device, ensure dry conditions and and
protect the device from external influences e.g. by using a
suitable bag.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• The storage temperature is the same as the range given in
the Technical data chapter.
• Remove the batteries from the device.
