Operating manual – Pyrometer BP17
Technical data
Parameter Value
Model BP17
Weight 220 g
Dimensions (height x width x depth in
mm)
185 x 40 x 135
Measuring range -50°C to 380°C (-58°F to 716°F)
Measuring range resolution 0.1 °C / °F
Accuracy ±2 °C or ±2.0% of the measured
value (the higher value applies) if
T>0°C
±3 °C of the measured value if
T≤0°C
Repeatability 0.5 °C
Degree of emission 0.95
Response time < 0.5 s
Spectral sensitivity 8 to 14 μm
Optical resolution (D:S) 10:1
Smallest measuring spot Ø 12.7 mm (distance 127 mm)
Automatic switch-off after approx. 6min (SCAN)
or approx. 15s (HOLD)
Operating conditions 0 - 50 °C, 10 - 90 % RH
Storage conditions -20 - 60 °C, <80 % RH
Power supply 9V battery
Laser output < 1 mW (630-660 nm)
Laser class II, 630-660 nm, < 1 mW
Scope of delivery
• 1 x Pyrometer BP17
• 1 x 9 V battery
• 1x Device bag
• 1 x Getting started guide
Transport and storage
Transport
For transporting the device use a suitable bag to protect it from
external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• Dry.
• Protected from dust and direct sunlight.
• With a cover to protect it from invasive dust, if necessary.
• Remove the batteries from the device.
