pyrometer BP21
Device depiction
Device depiction
°C/°F
SET
1
1
2
3
4
5
7
6
8
MODE
No. Designation
1 Dual laser pointer
2 Infrared sensor
3 Measurement button
4 Battery compartment with cover
5 MODEbutton
6 Laser/Upbutton
7 Light/Downbutton
8 Display
Display
MAX
SCAN HOLD
MIN
°C
°F
LH
9
10
11
12
13
14
15
16
17
18
19 20 21
No. Designation
9 Lower alarm thresholdindication
10 Temperature unitindication
11 Battery statusindication
12 MINindication
13 Emissivityindication
14 MAX/MIN temperatureindication
15 MAXindication
16 Measurement value display
17 SCANindication
18 HOLDindication
19 Laserindication
20 Continuous measurementindication
21 Upper alarm thresholdindication
