Trotec BP21 User Manual

EN 7
pyrometer BP21
Technical data
Parameter Value
Model BP21
Weight 177g
Dimensions (H x W x L) 108mmx 45mmx 150mm
Measuring range -35°C to 800°C
(-31°F to 1472°F)
Measuring range resolution 0.1 °C / °F
Laser output < 1mW (630–670nm)
Laser Class II, 630 to 670nm,
<1mW
Accuracy ±2°C(±4°F) or ±2.0% of
the measured value
(the higher value applies)
Emissivity Adjustable
Distance to measuring
spot diameter ratio
12:1
Smallest measuring spot ø12.5mm (distance 150mm)
Spectral sensitivity 8 to 14μm
Reaction time < 1s
Operating temperature 0°C to 50°C (32°F to 122°F)
Relative humidity during
operation
Max. 80 % relative humidity
Storage conditions -20 °C to 60 °C
Power supply 9 V battery
Switch-off After approx. 8seconds of
non-use
Scope of delivery
• 1 x Pyrometer BP21
• 1x 9 V battery
• 1x Device bag
• 1x Quick guide
Transport and storage
Notice
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device, use the bag included in the scope of
delivery in order to protect the device from external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• with a cover to protect it from invasive dust if necessary
• the storage temperature complies with the values specified
in the Technical data
• Batteries are removed from the device
Operation
Inserting the battery
Notice
Make sure that the surface of the device is dry and the
device is switched off.
22
23
1. Open the battery compartment by sliding open the battery
compartment cover(23).
2. Use the battery clip(22) to connect the new battery with
correct polarity.
3. Insert the battery in the battery compartment.
4. Close the cover of the battery compartment.
