Operating Manual – IDE 30 / 50 / 60
EN
B - 3
05. Technical data
Type IDE 30 Type IDE 50 Type IDE 60
Parameter Value Value Value
Article number 1.430.000.220 1.430.000.230 1.430.000.235
Electrical connection 230 V 230 V 230 V
Frequency 50 Hz 50 Hz 50 Hz
Nominal current max. 1,5 A 3,2 A 3,2 A
Air volume Air volume 760 m³/h 2000 m³/h 2000 m³/h
Fan Axial fan Axial fan Axial fan
Nominal heat output 30 kW 50 kW 60 kW
Temperature increase ∆T
1)
62 °C 62 °C 62 °C
Oil consumption max. 3,4 l/h 4,8 l/h 5,2 l/h
Tank capacity 50 l 68 l 68 l
Chimney connection ø 120 mm ø 150 mm ø 150 mm
Thermostat connection series series series
Combustion indirect indirect indirect
Sound pressure level
(at distance of 1 m)
76 dB (A) 78 dB (A) 78 dB (A)
Length 1100 mm 1365 mm 1365 mm
Width 490 mm 550 mm 550 mm
Height 755 mm 985 mm 985 mm
Weight 34,2 kg 56,7 kg 56,7 kg
1) indicates the temperature increase. ΔT + ambient temperature = exhaust air temperature
2) optional
Fuels
The following fuels have been approved for use with
the oil heating unit IDE heating oil EL, diesel.
