Trotec PAE 51 User Manual

EN 9
air cooler PAE 51 / PAE 51 B
1. Disconnect the device from the mains before refilling water
or putting ice packs into the device.
2. There are two ways to fill water into the tank. Choose
option2 if you want to add ice cubes or ice packs for
additional cooling.
ð Option1:
Open the water funnel(17).
ð Option2:
Make sure that the slider(15) is secured in the upper
position. Undo the locking clasps(14) and lift off the top
section of the device.
3. Fill the water tank(3) with fresh drinking water only.
Optionally, you can add ice cubes made of drinking water
for additional cooling.
ð Observe the minimum and maximum filling level at the
filling level indicator.
The water tank must be filled up to minimum filling level
to enable pump operation.
4. If required, put ice packs into the water tank(3) for
additional cooling.
5. Close the flap for the water funnel(17) or put the upper
section back onto the water tank and shut the locking
clasps(14).
6. Make sure that the device is neither damp nor wet on the
outside. Otherwise wipe it dry.

Trotec PAE 51 Specifications

General

Type	Portable evaporative air cooler
Control type	Touch
Product color	Black, White
Handles quantity	1
Number of wheels	4 wheel(s)
Carrying handle(s)	Yes
Airflow	663 m³/h
Air speed	7 m/s
Noise level	60 dB
Number of speeds	4
Water tank capacity	20 L
Timer duration (maximum)	15 h
Suitable for room area up to	60 m²
AC input voltage	220 - 240 V
Power source type	AC
AC input frequency	50 Hz
Package depth	390 mm
Package width	342 mm
Package height	897 mm
Package weight	8000 g
Air purifiers functions	Cooling, Fan
