EN 5
sound level measuring device Sl300
Technical data
Parameter Value
Model SL300
Article number 3.510.005.010
Measuring range 30dB to 130dB
Accuracy ±1.4dB
as per DINEN61672
Resolution 0.1 dB
Frequency range 31.5 Hz to 8kHz
Dynamic range 50 dB
Partial measuring ranges (01):30– 80dB
(02):50– 100dB
(03):80– 130dB
(04):30– 130dB(Auto)
Display response time 500 ms
Power supply 9V battery006P or NEDA1604
or IEC6F22
Alarm function OVER: Fallen below measuring
range UNDER: Fallen below
measuring range
Data hold function 50 data records
Time weighting FAST (-125ms);
SLOW (-1s)
Microphone 1/2-inch electret condenser
microphone
Operating conditions 0°C to 40°C with 10% to
90%RH
Storage conditions -10 °C to +60 °C with 10% to
75 %RH
Weight 230g
Dimensions (length x width x
height)
210 mmx 55 mmx 32 mm
Automatic switch-off Switch-off after approx. 15min
of non-use
Scope of delivery
• 1x Digital sound level meter
• 1 x Wind shield for microphone
• 1 x Mini screwdriver
• 1x 9V battery
• 1 x Quick guide
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device, use the bag included in the scope of
delivery in order to protect the device from external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• with a cover to protect it from invasive dust if necessary
• The storage temperature is the same as the range given in
the Technical data chapter.
• Remove the batteries from the device.
