Operating Manual – Electric hot air generator
EN
B - 2
SWITCHING OFF THE HEATER
Let the fan run for 3 minutes before turning the heater
off. Rotate the knob to the “0” position.
REGULATING THE THERMOSTAT
By rotating the knob that controls
the thermostat, you can regulate
the room temperature.
When the desired temperature is
reached the thermostat automatically
switches the resistance off but the fan continues working.
The appliance comes with a built in security device
that goes off automatically if the appliance should
happen to overheat.
If the security device should go off, let the appliance
cool down before looking for the cause of the problem.
Should the problem persist, contact the Service Centre.
PERIODIC STORAGE AND CONTROL
If the appliance is not used for a long period of time, it
should be cleaned before being put away. Store it in a
dry place and protect it from dust. When the appliance
is used again check to make sure that the electric
cable is not damaged. Should you have any doubts as
to the conditions of the appliance please contact the
Service Centre.
The appliance should be checked at least once a year.
Only qualified personnel authorized by the manufac-
turer must carry out all repairs.
SINGLING OUT PROBLEMS
Problem: Cause: Solution:
The appliance works but does not
heat
Resistance is burnt out
Thermostat control is broken
Replace
Replace
The appliance does not switch on Faulty motor
Power supply interrupted
Replace
Unplug the appliance and check
connection.
Limited air flow Air duct obstructed
Faulty motor
Clear the passage
Replace
TECHNICAL DATA
TDS 20 R TDS 50 R TDS 75 R TDS 120 R
Air displacement 305 m³/h 980 m³/h 1100 m³/h 1900 m³/h
Capacity 3 kW 4,5 / 9 kW 5 / 10 / 15 kW 0,15 / 15 / 30 kW
Absorbed current 13,04 A 13 A 21,7 A 43,3 A
Voltage 230 V / 50Hz 400 V / 50 Hz 400 V / 50 Hz 400 V / 50 Hz
Sound level 46 dB 55 dB 57 dB 61 dB
Size (mm) 250 / 245 / 315 340 / 335 / 410 395 / 380 / 445 860 / 565 / 645
Weight 4,7 kg 10,8 kg 19 kg 32,5 kg
